Vertical 5‑Axis

Dynamic accuracy in rotary axes reduces cycle times and produces a higher quality finish.

D-Series

Table:

300 mm diameter

11.81" diameter

X:

350 mm

13.7"

Y:

300 mm

11.8"

Z:

250 mm

9.8"

Rapid Traverse:

60 m / min

2,362 ipm


Table:

300 mm diameter

11.8" diameter

X:

300 mm

11.8"

Y:

500 mm

19.7"

Z:

350 mm

13.8"

Rapid Traverse:

60,000 mm/min

2,362 in/min

Maximum Workpiece:

450 diameter x 240 mm (conditional)

17.7" diameter x 10.6" high (conditional)


Pallet:

400 x 400 mm

15.7" x 15.7"

Table:

500 mm diameter

19.6" diameter,

X:

550 mm

21.6"

Y:

1,000 mm

39.4"

Z:

500 mm

19.7"

Rapid Traverse:

48,000 mm/min (X) 50,000 m/min (Y & Z)

1,890 in/min (X) 1,970 in/min (Y & Z)

Maximum Workpiece:

650 mm x 500 mm height (conditional)

25.6" diameter x 19.6" height (conditional)


Table:

800 mm  ø

31.5"  ø

X:

1,200 mm

47.24"

Y:

1,100 mm

43.30"

Z:

650 mm

25.59"

Rapid Traverse:

36,000 mm/min

1,417 ipm

Maximum Workpiece:

1,000 mm ø x 500 mm (with limitations)

39.4" ø x 21.65" (with limitations)

Spindle Taper:

CAT40 (HSK-A63 opt)

CAT40 (HSK-A63 opt)


X:

1,200 mm

47.24"

Y:

1,100 mm

43.30"

Z:

650 mm

25.59"

Rapid Traverse:

36,000 mm/min

1,417 ipm

Maximum Workpiece:

1,000 mm ø x 550 mm (with limitations)

39.4" ø x 21.65" (with limitations)

Spindle Taper:

CAT50 (HSK-A100)

CAT50 (HSK-A100)


Table:

300 mm x 340 mm

11.81" x 13.38"

X:

450 mm

17.7"

Y:

620 mm

25.6"

Z:

500 mm

19.7"

Rapid Traverse:

60,000 mm/min

2,362 ipm

Maximum Workpiece:

450 mm diameter x 400 mm (conditional)

17.7" diameter x 10.6 " (conditional)


F-Series

Table:

1,000 x 500 mm

39.4" x 19.7"

X:

900 mm

35.4"

Y:

500 mm

19.7"

Z:

450 mm

17.7"

Rapid Traverse:

20,000 mm/min

787 ipm

Maximum Workpiece:

200 mm diameter x 8.66 mm height (conditional)

7.87" x 19.7" x 17.7"


V-Series

Pallet:

90 mm diameter

Table:

3.5"Ø

X:

320 mm

12.6"

Y:

280 mm

11.0"

Z:

300 mm

11.8"

Rapid Traverse:

20,000 mm/min

787 in/min

Maximum Workpiece:

90 mm diameter x 100 mm height (conditional)

3.5"Ø x 3.93" height (conditional)


Pallet:

90 mm diameter

Table:

3.5"ø

X:

320 mm

12.6"

Y:

280 mm

11.0"

Z:

300 mm

11.8"

Rapid Traverse:

20,000 mm/min

787 in/min

Maximum Workpiece:

90 mm diameter x 100 mm height (conditional)

3.5"ø x 3.93" height (conditional)


Table:

200 mm diameter

7.8"ø

X:

650 mm

25.6"

Y:

325 mm

12.7"

Z:

350 mm

13.7"

Rapid Traverse:

20,000 mm/min

787 in/min

Maximum Workpiece:

250mm ø x 135 mm (conditional)

9.8"ø x 5.31" (conditional)


Table:

200 mm diameter

7.8"ø

X:

650 mm

25.6"

Y:

325 mm

12.7"

Z:

350 mm

13.7"

Rapid Traverse:

20,000 mm/min

787 in/min

Maximum Workpiece:

250mm diameter x 135 mm height (conditional)

9.8"ø x 5.31" (conditional)


Table:

200 mm diameter

7.87" diameter

X:

900 mm

35.4"

Y:

460 mm

18.1"

Z:

450 mm

17.7"

Rapid Traverse:

20,000 mm/min

787 in/min

Maximum Workpiece:

250 mm diameter x 310 mm height (conditional)

9.8" diameter x 12.2" height (conditional)


Table:

200 mm diameter

7.87" diameter

X:

900 mm

35.4"

Y:

460 mm

18.1"

Z:

450 mm

17.7"

Rapid Traverse:

20,000 mm/min

787 in/min

Maximum Workpiece:

250 mm diameter x 310 mm height (conditional)

9.8" diameter x 12.2" height (conditional)


Table:

1,300 mm x 1,000 mm

51.81" x 39.37"

X:

1,300 mm

51.2"

Y:

1,000 mm

39.3"

Z:

600 mm

23.6"

Rapid Traverse:

58,000 mm/min

2,283 in/min

Maximum Workpiece:

1,500 mm x 1,200 mm x 550 mm

59" x 47.42" x 21.65"


Table:

2,000 mm x 1,300 mm

78.73" x 51.18"

X:

2,000 mm

78.7"

Y:

1,300 mm

51.2"

Z:

800 mm

31.5"

Rapid Traverse:

58,000 mm/min

2,283 in/min

Maximum Workpiece:

2,200 mm x 1,500 mm x 700 mm

86.61" x 59.05" x 27.55"
